For spacecraft in orbit around Earth, changes to orbital parameters are caused by Earth's oblateness, gravitational attraction from the Sun and Moon, solar radiation pressure, and air drag. These perturbing forces must be counteracted by maneuvers to keep the spacecraft in the desired orbit. Perturbing forces caused by Earth's oblateness also perturb eccentricity, but near-circular orbits exist with no secular or long-periodic perturbations of the eccentricity vector, only periodic perturbations equal to the orbital period. Such an orbit is perfectly periodic (except for orbital plane precession) and is called a frozen orbit.

Reader's Guide

Frozen orbits are significant because they provide long-term stability for artificial satellites, reducing the need for station-keeping propellant. This is especially valuable for Earth observation missions where repeated observations under constant conditions are desirable. The classical theory of frozen orbits is based on analytical perturbation analysis for artificial satellites, considering the J2 and J3 terms of the geopotential model. For lunar orbits, scientists have identified four frozen lunar orbits at inclinations of 27°, 50°, 76°, and 86°, as lunar mascons make most low lunar orbits unstable. These orbits are often the preferred choice for Earth observation missions, including Sun-synchronous frozen orbits.

Did You Know?

• Four frozen lunar orbits have been identified at 27°, 50°, 76°, and 86° inclination.
• The orbit of the Apollo 15 subsatellite PFS-1 had an inclination of 28°, close to one of the frozen lunar orbits.
• For Sun-synchronous spacecraft, an appropriate inclination of 97.8–99.0 degrees is selected so that precession equals about 1 degree per day.

Orbits Defined by Their Central Body

The taxonomy of gravitational orbits begins with identifying which celestial object sits at the center of the path. At the broadest scale, a galactocentric orbit traces a loop around the core of a galaxy—the Sun itself follows this pattern as it circles the Milky Way's center. Stepping inward, heliocentric orbits encircle the Sun, encompassing every planet, comet, and asteroid in our Solar System, along with countless artificial satellites and fragments of space debris. Notably, moons do not qualify as heliocentric; they instead orbit their parent planet. Geocentric orbits center on Earth, accommodating both the Moon and human-made satellites. Selenocentric orbits (from Selene) describe paths around Earth's Moon, while areocentric orbits (from Ares) do the same for Mars. For the remaining planets—Mercury, Venus, Jupiter, Saturn, and Uranus—Greek-derived terms exist (hermeocentric, cytherocentric, zenocentric, kronocentric, uranocentric) but remain far less established in common usage than their Earth and Mars counterparts.

Altitude Tiers of Earth Orbit

Once an orbit is confirmed as geocentric, its altitude above the surface determines its practical category. Very low Earth orbit spans roughly 100 to 450 kilometers, while low Earth orbit extends up to 2,000 kilometers. Medium Earth orbit occupies the band between 2,000 km and just under 35,786 km, and it hosts the constellation of navigation satellites—GPS, GLONASS, Galileo, and BeiDou—with GPS spacecraft specifically at 20,200 km altitude and a period near twelve hours. At 35,786 km altitude (semi-major axis of 42,164 km), geosynchronous orbit matches Earth's sidereal rotation; a geostationary orbit is the special zero-inclination case that hovers over a fixed equatorial point. Beyond that altitude lies high Earth orbit. A transatmospheric orbit is a special case where the apogee clears 100 km but the perigee dips back into the atmosphere. Perturbation dynamics shift with altitude: below roughly 800 km, atmospheric drag dominates non-gravitational forces, whereas above that threshold solar radiation pressure takes over—though the crossover height fluctuates with solar activity.

Inclination and Direction of Travel

An orbit's tilt relative to a reference plane and its direction of travel further refine its classification. A non-inclined orbit lies flat against its reference plane—equatorial if that plane is the equator, ecliptic if it is the ecliptic. A near-equatorial orbit, with inclination close to zero, grants a single spacecraft rapid revisit capability over equatorial ground sites. At the opposite extreme, a polar orbit sweeps over both poles each revolution, carrying an inclination near 90 or −90 degrees. The polar Sun-synchronous variant adds the constraint of crossing the equator at the same local solar time every pass, a property that keeps shadow patterns consistent and makes it ideal for imaging satellites. Directionally, a prograde orbit travels with the primary's rotation (eastward on Earth) and is conventionally assigned an inclination under 90 degrees; a retrograde orbit runs against that rotation and is specified above 90 degrees. Few Earth satellites are deliberately launched retrograde because the rocket already inherits an eastward velocity component from the planet's spin, so flying against it demands extra fuel.

Eccentricity: From Circles to Escape

The shape of an orbit is governed by its eccentricity, and the taxonomy splits paths into closed (periodic) and open (escape) families. Circular orbits, with an eccentricity of exactly zero, trace a perfect circle. Elliptical orbits carry an eccentricity between zero and one, producing a stretched oval. Parabolic and hyperbolic paths are open—vehicles on them never return—while radial orbits can belong to either family. Two named elliptical trajectories deserve special attention. The geostationary or geosynchronous transfer orbit (GTO) places its perigee at low-Earth-orbit altitude and its apogee at the geostationary altitude, serving as a stepping-stone for communication satellites. The Hohmann transfer orbit is a maneuver that moves a spacecraft between two circular orbits, representing one of the most fuel-efficient ways to change altitude. Together, these classifications—centric, altitude-based, inclination-based, directional, and eccentricity-based—form a comprehensive framework for describing any gravitational path in space.
